G7

The overall appearance of Falcon G7 is miniaturised and lightweight as the main keynote. The sturdy lines and light appearance are convenient for carrying out measurement operations.

Availability: In stock

$17,000.00 $14,800.00

Qty :
Compare

Features

Galaxy G7



The Most Complete Satellites Receiver

SOUTH G7 comes with the latest generation 965 channels motherboard supports all constellations (GPS, GLONASS, BeiDous, GALILEO, QZSS and etc.), all signals in one unit for superb performance, stability and accuracy.

Specification

Satellite signals tracked simultaneously Signal tracking 965 channels
GPS: L1, L1C, L2C, L2P, L5
GLO: G1, G2, G3
BDS: BDS-2: B1I, B2I, B3I BDS-3: B1I, B3I, B1C, B2a, B2b*
GAL: E1, E5A, E5B, E6C, AltBOC*
QZSS: L1, L2C, L5*
SBAS: L1*
IRNSS: L5*
MSS L-Band (Reserve)
Positioning output rate:1Hz~20Hz
GNSS features Initialization time: <10s
Initialization reliability: >99.99%
Positioning precision Code differential GNSS positioning Horizontal: ±0.25m+1ppm Vertical: ±0.50m+1ppm
SBAS positioning accuracy: Typically<5m 3DRMS
Static GNSS surveying Horizontal: ±2.5mm+0.5ppm Vertical: ±5mm+0.5ppm
Real-time kinematic surveying Horizontal: ±8mm+1ppm Vertical: ±15mm+1ppm
Network RTK Horizontal: ±8mm+0.5ppm Vertical: ±15mm+0.5ppm
IMU tilt angle 0°~60°
User interaction Operaing system Linux
Buttons Onebutton operation
Indicators Fourindicate lights
Web UI Freely to configure and monitor the receiver by accessing to the web server via Wi-Fi and USB
Voice guide iVoice intelligent voice technology provides status and voice guide
Supporting Chinese, English, Korean, Russian, Portuguese, Spanish, Turkish and user define
Secondary development Providing secondary development package
Hardware performance Dimension 135mm(Diameter)x84.75mm(Height)
Weight 0.97kg (battery included)
Material Magnesium aluminum alloy shell
Operating -45°C~+70°C
Storag -55°C~+85°C
Humidity 100% Non-condensing
Waterproof/Dustproof IP67 standard, protected from long time immersion to depth of 1m
IP67 standard, fully protected against blowing dust
Shock and vibration Withstand 2 meters pole drop onto the cement ground naturally
Power Supply 9-28V DC, overvoltage protection
Battery Internal Li-on, 6800mAh, 3.7V
Battery life Static mode 10 h, Rover mode 8h,Base mode 8h
Communications I/O port 5PIN LEMO external power port + RS232, 7PIN external USB(OTG)+Ethernet
1 radio antenna interface
Wireless modem Built-in radio, 1W, typically work range can be 5KM
Radio repeater
Frequency Range 410-470MHz
Communication Protocol Farlink, Trimtalk450s, SOUTH, HUACE, Hi-target, Satel
Double Module Bluetooth BLEBluetooth 4.0 standard, support for android, ios cellphone connection
Bluetooth 2.1 + EDR standard
NFC Communication Realizing close range (shorter than 10cm) automatic pair between receiver and controller
(controller equipped NFC wireless communication module needed)
WIFI Standard 802.11 b/g standard
WIFI Hotspot The WIFI hotspot allows any mobile terminal to connect and access to the internal webserver for the control and moditor receiver
WIFI data link To work as the datalink that receiver is able to broadcast and receive differential data via WIFI
Data storage/ Transmission Data Storage 8GB SSD internal storage
Support external USB storage and automatical cycle storage
Changeable record interval, up to 20Hz raw data collection
Data Transmission USB data transmission, supporting FTP/HTTP data download
Data Format Differential data format: RTCM 2.1, RTCM 2.3, RTCM 3.0, RTCM 3.1, RTCM 3.2
Output format: ASIC (NMEA-0813), Binary code (SOUTH Binary)
Network model support: VRS, FKP, MAC, fully support NTRIP protocol
Inertial sensing system Tilt angle Up to 60 degrees
Electronic bubble Controller software display electronic bubble, checking leveling status of the centering rod real time
Thermometer Built-in thermomter sensors, adopting intelligent temperature control technology which can monitor and adjust the temperature of receiver in real time

Note: all information above is subject to change without any prior notice.
