Features
A Typical SURVEYOR-ORIENTED Mapping Drone
Why surveyor-oriented? FLYme is specifically made for professional aerial mapping.
Worried about drone crash or drone loss? FLYme is particularly designed for flight safety control.
Which ranges to perfectly use for? A variety of applications include…
Specification
Aircraft System | aircraft type | fixed-wing |
wingspan | 150 cm | |
take-off weight | 3.5 kg (including camera and drone battery) | |
power supply | lithium polymer battery, one unit | |
battery power | 7000 mAh, 6S, 22.2V | |
body material | industrial EPO foam | |
Flight Performance | take-off method | typical, hand launch; optional, catapult launch |
landing method | typical, precise parachute landing; optional, belly landing | |
maximum ceiling | 4000 m | |
working height | typical 120-1400 m | |
cruising speed* | typical 20 m/s (72 km/h) | |
endurance | not less than 59 minutes, best up to 90 minutes (upon customization) | |
single flight range* | maximum 92 km | |
single flight coverage* | maximum 60 sq.km (6,000 ha) @ GSD 20cm | |
landing space | precise landing control within 6 m radius | |
Operation Performance | base observations | integrated with radio datalink device |
radio datalink | Frequency Hopping Spread Spectrum (FHSS) | |
control frequency | 1W, 915 MHz (869 MHz or 2.4 GHz optional) | |
radio communication range | typical, 5-10 km; maximum 30 km | |
weather limit | beaudfort scale 6, 10.8-12.7 m/s | |
operating temperature | -10℃ to 50℃ | |
Ground Control | auto return | upon indications of low battery, high temperature, heavy wind, 30sec radio disconnection and imaging failure |
drone tracking | APP display via pre-installed GPS tracker |
Note1: all aspects marked with * are determined by weather conditions and manual operations in practice.
Note2: all information above is subject to change without any prior notice.
